CORTECS Columns

CORTECS Columns

Solid-core columns that live up to their potential.

Solid-core columns that live up to their potential.

Your lab needs to develop methods for challenging separations even faster. Increase resolution for even your toughest samples with the enhanced column efficiency of CORTECS solid-core columns, which provide the flexibility and power you need to rapidly separate a wide array of compounds.

CORTECS Columns are available in reversed-phase and HILIC options across seven column chemistries with different particle characteristics and innovative charged surface modifications for 20% faster separations* and 25% more resolution at low operating back pressures.

*As compared to fully porous particle columns.

CORTECS Columns Family, 3 Columns 3 CORTECS Columns

Introducing 5 µm CORTECS Premier Columns

Introducing 5 µm CORTECS Premier Columns

If you love solid-core particles and want to eliminate doubt from your chromatography, CORTECS Premier Columns combine your favorite particle with MaxPeak High Performance Surfaces.

With expanded particle size options, you can now experience the seamless scalability, speed, sensitivity, resolution, and confidence of CORTECS Premier Columns — no matter what HPLC system you use.

XBridge XSelect Premier Column

CORTECS Premier Columns are available in three particle sizes with three reversed-phase chemistries for UPLC, UHPLC, and HPLC analysis.

CORTECS Premier Columns are available in three particle sizes with three reversed-phase chemistries for UPLC, UHPLC, and HPLC analysis.

Specifications

Overview

  • Maximize efficiency with high-performance columns created using state-of-the-art column packing techniques, bonding and end-capping processes.

  • Achieve greater throughput and speed than fully porous particle columns.

  • Get simple and seamless transfer with consistent results across different particle sizes and column configurations.

  • Flexibly develop methods for challenging separations faster with reversed-phase and HILIC options across seven column chemistries.

  • Prolong column lifetimes with optional VanGuard Cartridges and pre-columns specifically designed using CORTECS stationary phases.

Recommended Use: To maximize resolution and speed for all LC separations.


CORTECS Column Characteristics

CORTECS Column Characteristics

CORTECS C18+ Columns
  • General purpose
  • High efficiency
  • Reversed-phase column

A positively charged surface delivers excellent peak shape for basic compounds at low pH.

CORTECS C18 Columns
  • General purpose
  • High efficiency
  • Reversed-phase column

Balanced retention of acids, bases, and neutrals at low and mid-range pH.

CORTECS C8 Columns
  • General purpose
  • High efficiency
  • Reversed-phase column

Similar selectivity but shorter retentivity when compared to C18 columns.

CORTECS T3 Columns
  • General purpose
  • High efficiency
  • Reversed-phase column

Enables to use of 100% aqueous mobile phase and increased retention of polar compounds.

CORTECS Phenyl Columns
  • High efficiency
  • Method development column

Provides alternate selectivity, particularly for polyaromatic compounds.

CORTECS Shield RP18 Columns
  • High efficiency
  • Method development column

Provides alternate selectivity, particularly for phenolic compounds.

CORTECS HILIC Columns
  • General purpose
  • High efficiency
  • HILIC Column

Offers orthogonal selectivity when compared to reversed-phase columns.


Reliable columns. Consistent performance.

Get consistent batch-to-batch performance year after year with reliable CORTECS Columns.


Method transfer just got easier.

Get the versatility you need for seamless method transfer, with consistent results and fully scalable particle sizes for HPLC, UHPLC, and UPLC platforms.


Increased resolution and increased throughput.

Maximize column efficiency and throughput with increased resolution for the toughest samples on any LC system.



Resources

Documents

Documents


Support

Support

Related

Prolong analytical column lifetime while maintaining chromatographic performance with VanGuard Pre-columns and cartridges.

Get HPLC and UHPLC method compatibility at the flip of a switch with this versatile, modern LC system.

Get faster separations with higher resolution and sensitivities using sub-2-µm particles at 1241 bar pressures with UPLC Columns.

Offers and Discounts

Back To Top Back To Top
CORTECS Columns

The CORTECS Columns family redefines efficiency in liquid chromatography with its solid-core technology, designed to meet the demands of challenging separations with unparalleled speed and resolution. Available in both reversed-phase and HILIC formats, CORTECS columns offer seven distinct column chemistries, each featuring innovative charged surface modifications. This design enables 20% faster separations and 25% greater resolution at significantly lower operating back pressures compared to traditional fully porous particle columns.

Crafted using advanced column packing techniques and bonding and end-capping processes, CORTECS Columns ensure maximum performance and durability. They outpace fully porous particle columns in throughput and speed, making them an ideal choice for labs looking to enhance their LC separations efficiency.

With the CORTECS range, method development becomes more flexible and streamlined, allowing for rapid separation of a wide array of compounds across different particle sizes and column configurations. This versatility is further enhanced by the optional VanGuard Cartridges and pre-columns, which are specially designed to prolong column lifetimes and maintain consistent performance.

CORTECS Columns are recommended for any LC separation task, promising not only to maximize resolution and speed but also to deliver consistent batch-to-batch performance year after year. They simplify method transfer across HPLC, UHPLC, and UPLC platforms, offering seamless scalability and reliability. For laboratories looking to push the boundaries of what's possible in liquid chromatography, CORTECS Columns provide a solid foundation for achieving greater efficiency, throughput, and resolution in all LC analyses.

CORTECS Columns FAQs

What types of particles are used in CORTECS columns?
CORTECS columns utilize solid-core (also known as superficially porous) particle technology to deliver high-efficiency separations. These particles consist of a solid silica or hybrid core surrounded by a porous outer layer, combining the speed and resolution benefits of sub-2-µm particles with lower backpressure compared to fully porous materials.

The CORTECS family includes both silica-based and bridged ethyl hybrid (BEH) solid-core particles, each designed to offer enhanced mechanical strength and stability under varying pH and temperature conditions. This particle architecture reduces band broadening, improves mass transfer, and enables sharper peaks and faster run times, making CORTECS columns ideal for high-throughput and complex analytical workflows.

Which chromatographic modes are supported by CORTECS columns?
CORTECS columns are available in a range of bonded chemistries that support multiple chromatographic modes, primarily within reversed-phase liquid chromatography. These include C18, C18+, Shield RP18, T3, and HILIC options, offering flexibility for separating a wide variety of compounds from highly hydrophobic to polar analytes.

The Shield RP18 provides enhanced selectivity for basic compounds, while the T3 phase allows for better retention of polar analytes. Additionally, CORTECS HILIC columns support hydrophilic interaction chromatography, suitable for polar and ionic compounds. With these chemistries, CORTECS columns can address diverse application needs in pharmaceutical, environmental, food, and bioanalytical testing.

Can CORTECS columns be used for peptide or protein separations?
While CORTECS columns are primarily designed for small molecule separations, they can be suitable for short peptides and small protein fragments under certain conditions. The solid-core particle design offers high efficiency and sharp peak shapes, which can be advantageous when analyzing relatively small, hydrophilic biomolecules.

However, for intact protein separations or complex peptide mapping workflows, Waters recommends columns specifically designed for biomolecules, such as the ACQUITY UPLC Protein BEH or Peptide BEH columns. That said, CORTECS T3 and Shield RP18 chemistries may be used in bioanalytical workflows where small peptides or peptide-like drug candidates are the focus, especially when high throughput and LC-MS compatibility are needed.
